The Decorum® 0.125 gpf urinal system from American Standard uses a Selectronic® battery-powered flush valve and offers an impressive 87.5% water savings when compared to a standard 1 gpf urinal. Includes the innovative EverClean® surface to help inhibit the growth of bacteria, mold and mildew for a cleaner urinal. Deep sump reduces splashing Washout urinal works at 0.125 gpf permanent EverClean® surface inhibits the growth of stain and odor causing bacteria, mold and mildew on the surface 3/4 in inlet spud outlet connection threaded 2 in inside (NPTF) strainer included. Meets ANSI flush requirements at 0.125 gpf. Meets California water savings regulations sustainability CEC listed. CalGreen compliant. Award winning - recipient of the buildings magazine 2016 money-saving products, The Decorum® 0.125 gpf urinal system with Selectronic® battery-powered flush valve provides cost savings for commercial buildings.
American Standard Urinal System, Collection: Decorum®, Flush Rate: 0.125 gpf, Flushing System: Wash-Down, Spud Location: Top, 3/4 in Inlet Spud, Working Pressure: 20 to 80 psi, Vitreous china, White, 14 in L, 13-5/16 in W, 21-1/2 in H
| Collection | : | Decorum® |
| Finish | : | White |
| Flush Rate | : | 0.125 gpf |
| Flushing System | : | Wash-Down |
| Height | : | 21-1/2 in |
| Inlet Spud Size | : | 3/4 in |
| Length | : | 14 in |
| Material | : | Vitreous China |
| Spud Location | : | Top |
| Width | : | 13-5/16 in |
| Working Pressure | : | 20 to 80 psi |
- Sleek, modern, compact design
- Permanent EverClean® surface inhibits the growth of stain and odor causing bacteria, mold and mildew on the surface
- Powerful wash-down flushing action with deep sump to reduce splashing
- 3/4 in inlet spud with 2 in threaded outlet connection
- Touchless piston-operated flush valve
- 8 year CR-P2 lithium battery installed in valve
- Exclusive DynaClean® self-cleaning wiper spring technology
- Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
- Fully mechanical manual override can operate without power
