The CL360 is an automatically ranging true root mean squared digital open jaw fork meter that measures AC current via the fork, AC/DC voltage, continuity and resistance via test leads. It can detect the presence of voltage via the integrated non-contact voltage tester.
KLEIN TOOLS® Open Jaw Fork Meter, 600/1000 V, 200 A, 60 MOhm Resistance, 0.58 in Jaw, 6000, LCD Display, CAT III Class 2, Plastic, 2.9 in H x 5.13 in W x 12.25 in D
| Amperage Rating | : | 200 A |
| Counts | : | 6000 |
| Dimensions | : | 2.9 in H x 5.13 in W x 12.25 in D |
| Display Type | : | LCD |
| Jaw Capacity | : | 0.58 in |
| Material | : | Plastic |
| Resistance | : | 60 MOhm |
| Safety Rating | : | CAT III Class 2 |
| Voltage Rating | : | 600/1000 V |
- Automatically ranging true root mean squared (TRMS) measurement technology for accuracy
- Wide jaw for measuring current in cables up to 3/0 sizes, accommodates cables of diameter up to 0.58 in (14.7 mm)
- Non-contact voltage tester integrated into the jaw
- Jaw and housing - CATIV 600V/CATIII 1000V, Electrical - CATIII 600V/CATII 1000V, Class 2, double insulation
- Backlit display for clear readings
- Powers off automatically after 15 min of non-use to conserve battery life
- Rugged Klein touch meter is built to withstand a 9.9 ft drop
- Low battery indicator and easily accessible battery compartment
- Before each use verify meter operation by measuring a known voltage or current
- Never use the meter on a circuit with voltages that exceed the category based rating of this meter
- Usage of this meter in any way other than that specified by the manufacturer can impair safe operation, resulting in severe injury or death
Specification Sheet
