RWV® Ball Valve, Series: Eco-Valve Series, 3/4 in Nominal, EzGRIP Push-Fit Connection, Full Port, 200 lb Pressure Class, 3.08 in Inlet to Outlet Length, 2-1/4 in Top to Inlet Center, Handle Operator, ASTM A36, ASTM B124-C37700, ASTM B927-C28450 Material Standard, Brass Body, PTFE Seat, Brass Stem, PTFE Packing Material, Steel Handle, Brass Ball, Lead-Free Lead-Free/Contains Lead
| Ball Material | : | Brass |
| Body Material | : | Brass |
| Connection Type | : | EzGRIP Push-Fit |
| Handle Material | : | Steel |
| Inlet to Outlet Length | : | 3.08 in |
| Lead-Free/Contains Lead | : | Lead-Free |
| Material Standard | : | ASTM A36, ASTM B124 C37700, ASTM B927 C28450 |
| Nominal Size | : | 3/4 in |
| Operator Type | : | Handle |
| Packing Material | : | PTFE |
| Port Type | : | Full |
| Pressure Class | : | 200 lb |
| Seat Material | : | PTFE |
| Series | : | Eco-Valve Series |
| Stem Material | : | Brass |
| Top to Inlet Center | : | 2-1/4 in |
- Adjustable packing
- Blowout-proof stem
- Works with copper, CPVC and Pex tubing
- Field adjustable and removable
Instruction/Installation Manual
